Andamiro Co., Ltd.

TICKET REDEMPTION

NEW

SpongeBob Pirates of Bikini Bottom Let's go for treasure of pirates with Spongebob!

Short url COPY http://www.andamiro.com/games/pirates

Tags Ticket

Dimensions 1,772mm x 1,201mm x 2,561mm
70" x 47" x 101"

Packing Dimensions 1,150mm x 1,870mm x 2,190mm
45" x 74" x 86"

Product Weight 455 kg / 1,003 lbs

Packing Weight 492 kg / 1,085 lbs

Power 700W

INQUIRY

PARTS INQUIRY

INQUIRE
CATEGORY OF QUESTIONS	TYPE OF QUESTIONS
AREA	AREA
COUNTRY	COUNTRY
Your Name (required)	Your Name (required)
Your Email (required)	Your Email (required)
Subject	Subject
Select Parts	Select Parts
Your Message	Your Message
FILE UPLOAD ##1	FILE UPLOAD ##1
FILE UPLOAD ##2	FILE UPLOAD ##2
CAPTCHA	CAPTCHA
NEWS LETTER	NEWS LETTER Yes! I would like to receive ANDAMIRO's newsletter.
CAPTCHA
I agree to the collection and use of personal information.

SUPPORT

Leaflets (1)
Manuals (3)
Document (1)
Trouble shooting
Video List (9)

FEATURES

Let's go for treasure of pirates with Spongebob!

Card + Chip + Video + Ball Pusher!

Brand new concept!!

· Easy for everyone!

· New concept of Ball Pusher game!

· Various of missions and mini games!

GALLERY

Sorry, this is not available at the moment.

PARTS

동기화 작업중입니다.
페이지를 이동하거나 닫으면 오류가 발생할 수 있습니다.

Total 216Parts

No.	Part name Part picture	Code Info	Part picture	Part Add

1	[] PHOTO SENSOR LG-217L3	[] PHOTO SENSOR MELE0PHO007	Part picture
1	TERMINAL BLOCK 250V 10P UL_CE	TERMINAL BLOCK MELE0TEB003	Part picture
2	VOLUME KNOB CAP BLUE	VOLUME KNOB MELE0VOL007	Part picture
3	BEARING MR126ZZ,	BEARING MZZZ0BEA005	Part picture
4	BEARING 6900ZZ	BEARING MZZZ0BEA007	Part picture
5	KEY ONLY 7001 2EA 1SET_WITH RING	KEY ONLY 7001 MZZZ0KEY035	Part picture
6	KEY ONLY 6001 2EA 1SET _WITH RING	KEY ONLY 6001 MZZZ0KEY014	Part picture
1.6.1	[KEY ONLY 6001] DC FAN 80MM 2BALL DFH8025B12	[KEY ONLY 6001] DC FAN 80MM 2BALL MZZZ0FAN015	Part picture
7	PHOTO INT-2 PCB ASS'Y WINNER,WON,CIR공용	PHOTO INT-2 PCB ASS'Y AWIW0PCB009	Part picture
8	FERRITE CORE RU(TU)1335	FERRITE CORE MELE0FER001	Part picture
9	BUTTON SWITCH TICKET AM1PB-26SH R12D	BUTTON SWITCH MMUM0BUT002	Part picture
10	PUSH BUTTON SWITCH DS-412R ROSH	PUSH BUTTON SWITCH MELE0PUS006	Part picture
11	BEARING 638ZZ	BEARING MZZZ0BEA064	Part picture
12	AC MOTOR SSR PCB ASS'Y AC MOTOR SSR	AC MOTOR SSR PCB ASS'Y AENS0PCB001	Part picture
13	Z MOTOR PART TENSION SPRING .	Z MOTOR PART TENSION SPRING MWID0SPR001	Part picture
14	KEY ASS'Y 6001 6001 ONLY BODY	KEY ASS'Y 6001 MZZZ0KEY075	Part picture
15	KEY ASS'Y 7001 7001 ONLY BODY	KEY ASS'Y 7001 MZZZ0KEY076	Part picture
1.15.1	[KEY ASS'Y 7001] AC INPUT DAC-13H	[KEY ASS'Y 7001] AC INPUT MELE0SWI015	Part picture
16	HAND BOLT M4, PKB4 4*10L	HAND BOLT MZZZ0PLA030	Part picture
17	AC INPUT ASS'Y DAC-13H,WITH FUSE10A_2EA	AC INPUT ASS'Y AELE0FUS002	Part picture
1.17.1	[AC INPUT ASS'Y] FUSE 10A 0218010.MXP 250V,10A,4PA	[AC INPUT ASS'Y] FUSE 10A MELE0FUS018	Part picture
18	BEARING F688ZZ	BEARING MZZZ0BEA076	Part picture
19	SETUP LCD PCB ASS'Y UNISYSTECH	SETUP LCD PCB ASS'Y AZZZ0PCB113	Part picture
20	SPEAKER MID 4.5"+TW1/2" 8Ω W-C-100 F BK	SPEAKER MZZZ0SPE021	Part picture
21	FND PCB ASS'Y 6390-4(STRAIGHT)	FND PCB ASS'Y AFND0PCB011	Part picture
22	GEAR HEAD K6G90C_AC MOTOR	GEAR HEAD MSAW0ZZZ008	Part picture
23	LED STICK BAR BRK 12MM 90도	LED STICK BAR BRK MELE0000022	Part picture
1.23.1	[LED STICK BAR BRK] SPRING AMHP-014A	[LED STICK BAR BRK] SPRING MZZZ0SPR002	Part picture
2.23.1	[LED STICK BAR BRK] TIMMING BELT 52MXL,W4.8 RUBBER	[LED STICK BAR BRK] TIMMING BELT MZZZ0BEL018	Part picture
3.23.1	[LED STICK BAR BRK] TIMMING BELT 147MXL,W4.8 RUBBER	[LED STICK BAR BRK] TIMMING BELT MZZZ0BEL019	Part picture
24	BEARING F6800ZZ, D10 D19 B5	BEARING MZZZ0BEA092	Part picture
25	LED BAR 12V ASS'Y 460MM	LED BAR 12V ASS'Y AZZZ0PCB124	Part picture
1.25.1	[LED BAR 12V ASS'Y] CARD DISPENSOR I/O PCB ASS'Y CARD DISPENSOR	[LED BAR 12V ASS'Y] CARD DISPENSOR I/O PCB ASS'Y ASBP0PCB008	Part picture
26	MOTOR KGC-3429-075-1/210_31RPM	MOTOR MZZZ0MOT088	Part picture
1.26.1	[MOTOR] MOTOR KGC-040-3429C	[MOTOR] MOTOR MZZZ0MOT089	Part picture
2.26.1	[MOTOR] BEARING F686ZZ	[MOTOR] BEARING MZZZ0BEA094	Part picture
3.26.1	[MOTOR] TIMMING PULLEY MXL-47	[MOTOR] TIMMING PULLEY MZZZ0PLA039	Part picture
4.26.1	[MOTOR] TIMMING PULLEY MXL-29	[MOTOR] TIMMING PULLEY MZZZ0PLA040	Part picture
5.26.1	[MOTOR] CARD DISPENSER RUBBER HOUSING-A	[MOTOR] CARD DISPENSER RUBBER HOUSING-A MZZZ0RUB017	Part picture
6.26.1	[MOTOR] CARD DISPENSER RUBBER HOUSING-B 실리콘	[MOTOR] CARD DISPENSER RUBBER HOUSING-B MZZZ0RUB018	Part picture
7.26.1	[MOTOR] TIMMING BELT TENSION ROLLER .	[MOTOR] TIMMING BELT TENSION ROLLER MSBP0PRO017	Part picture
8.26.1	[MOTOR] DU BUSH 0608DU	[MOTOR] DU BUSH MZZZ0BEA096	Part picture
9.26.1	[MOTOR] CARD OUTLET GUIDE BLOCK ABS	[MOTOR] CARD OUTLET GUIDE BLOCK MZZZ0PLA042	Part picture
27	MONITOR CABLE HDMI_HDMI 2M	MONITOR CABLE MZZZ0HAN053	Part picture
28	CARD HEAVY PUSH BKT .	CARD HEAVY PUSH BKT MSBP0MEP023	Part picture
1.28.1	[CARD HEAVY PUSH BKT] BEARING GUIDE PIN CHIP HOPPER	[CARD HEAVY PUSH BKT] BEARING GUIDE PIN MZZZ0HOP033	Part picture
2.28.1	[CARD HEAVY PUSH BKT] CHIP HOPPER OUTER RING CHIP HOPPER	[CARD HEAVY PUSH BKT] CHIP HOPPER OUTER RING MZZZ0HOP035	Part picture
3.28.1	[CARD HEAVY PUSH BKT] CHIP HOPPER COIN SHOOTER RINK SHAFT-B CHIP HOPPER	[CARD HEAVY PUSH BKT] CHIP HOPPER COIN SHOOTER RINK SHAFT-B MZZZ0HOP036	Part picture
4.28.1	[CARD HEAVY PUSH BKT] CHIP HOPPER DISK CHIP HOPPER	[CARD HEAVY PUSH BKT] CHIP HOPPER DISK MZZZ0HOP038	Part picture
5.28.1	[CARD HEAVY PUSH BKT] CHIP HOPPER MOTOR BUSHING CHIP HOPPER	[CARD HEAVY PUSH BKT] CHIP HOPPER MOTOR BUSHING MZZZ0HOP039	Part picture
6.28.1	[CARD HEAVY PUSH BKT] CHIP HOPPER PIPE CHIP HOPPER	[CARD HEAVY PUSH BKT] CHIP HOPPER PIPE MZZZ0HOP040	Part picture
7.28.1	[CARD HEAVY PUSH BKT] CHIP HOPPER PIPE CHIP HOPPER	[CARD HEAVY PUSH BKT] CHIP HOPPER PIPE MZZZ0HOP040	Part picture
8.28.1	[CARD HEAVY PUSH BKT] COIN GUIDE PLATE PIN .	[CARD HEAVY PUSH BKT] COIN GUIDE PLATE PIN MZZZ0HOP043	Part picture
9.28.1	[CARD HEAVY PUSH BKT] BEARING 685ZZ	[CARD HEAVY PUSH BKT] BEARING MZZZ0BEA107	Part picture
10.28.1	[CARD HEAVY PUSH BKT] HOPPER RAIL BALL GUIDE .	[CARD HEAVY PUSH BKT] HOPPER RAIL BALL GUIDE MZZZ0ELH031	Part picture
11.28.1	[CARD HEAVY PUSH BKT] HOPPER DISK FILM .	[CARD HEAVY PUSH BKT] HOPPER DISK FILM MZZZ0ELH032	Part picture
29	L6205 HOPPER PCB ASS'Y 공용	L6205 HOPPER PCB ASS'Y AZZZ0PCB141	Part picture
30	MONITOR CABLE NM-HD03GZ HDMI_DVI 3M	MONITOR CABLE NM-HD03GZ MZZZ0HAN064	Part picture
31	COIN SELECTOR TW-389	COIN SELECTOR MZZZ0COS052	Part picture
32	AC MOTOR 220V K6IG6NC CE	AC MOTOR 220V MZZZ0MOT111	Part picture
1.32.1	[AC MOTOR 220V] CHIP HOPPER PCB ASS'Y CHIP HOPPER DRIVER	[AC MOTOR 220V] CHIP HOPPER PCB ASS'Y AZZZ0PCB153	Part picture
33	NOISE FILTER RNS-2010	NOISE FILTER MELE0NOI009	Part picture
34	POWER SMPS RSP-320-12	POWER SMPS MELE0SMP109	Part picture
35	BEARING DR19-B	BEARING MZZZ0BEA117	Part picture
36	ELEVATOR DISK SENSOR PCB ASS'Y GHP_REZ	ELEVATOR DISK SENSOR PCB ASS'Y AGHP0PCB020	Part picture
37	PIN SHAFT MOLD MOLD	PIN SHAFT MOLD MGHP0PLA004	Part picture
38	ELEVATOR WASHER MOLD MOLD	ELEVATOR WASHER MOLD MGHP0PLA005	Part picture
39	LED BAR 12V ASS'Y 710MM	LED BAR 12V ASS'Y AZZZ0PCB165	Part picture
40	ROCKER SWITCH R595KDF	ROCKER SWITCH MELE0SWI021	Part picture
1.40.1	[ROCKER SWITCH] MOTOR KGE-0162-KD3429T1-SSF	[ROCKER SWITCH] MOTOR MZZZ0MOT134	Part picture
41	BONUS TARGET SENSOR PCB ASS'Y .	BONUS TARGET SENSOR PCB ASS'Y AWWE0PCB005	Part picture
42	LM BEARING SL10UU	LM BEARING MZZZ0BEA125	Part picture
43	MOTOR KGV-0120-ND3657 U1	MOTOR MZZZ0MOT141	Part picture
44	BONUS TARGET LM SHAFT .	BONUS TARGET LM SHAFT MWWE0PRO007	Part picture
45	BONUS TARGET SHAFT BUSHING .	BONUS TARGET SHAFT BUSHING MWWE0PRO008	Part picture
1.45.1	[BONUS TARGET SHAFT BUSHING] SSD HP S700 120	[BONUS TARGET SHAFT BUSHING] SSD MZZZ0MEM025	Part picture
2.45.1	[BONUS TARGET SHAFT BUSHING] MAIN BOX .	[BONUS TARGET SHAFT BUSHING] MAIN BOX AWWE0SYS002	Part picture
2.45.1	[BONUS TARGET SHAFT BUSHING] RAM_V1 LPDDR3 4GB PC3L-12800 SAMSUNG	[BONUS TARGET SHAFT BUSHING] RAM_V1 MZZZ0000698	Part picture
2.45.2	[BONUS TARGET SHAFT BUSHING] RAM_V1 LPDDR3 4GB PC3L-12800 SAMSUNG	[BONUS TARGET SHAFT BUSHING] RAM_V1 MZZZ0000698	Part picture
46	POWER SMPS RSP-320-5V	POWER SMPS MELE0SMP126	Part picture
47	BEARING 6900ZZNR	BEARING MZZZ0BEA129	Part picture
48	SERIAL HUB PCB ASS'Y 공용	SERIAL HUB PCB ASS'Y AZZZ0PCB194	Part picture
49	COUPLING JOC30 10*10_M6_TAB120	COUPLING JOC30 MZZZ0COP001	Part picture
1.49.2	[COUPLING JOC30] MAIN IO PCB ASS'Y SPONGEBOB PIRATES	[COUPLING JOC30] MAIN IO PCB ASS'Y ASPP0PCB001	Part picture
50	MOTOR DRIVER IO SPONGBOB PIRATES	MOTOR DRIVER IO ASPP0PCB002	Part picture
51	WHEEL FAIL BALL CHECK PCB TRANSMITTING SPONGBOB PIRATES	WHEEL FAIL BALL CHECK PCB TRANSMITTING ASPP0PCB003	Part picture
52	WHEEL FAIL BALL CHECK PCB RECEIVING SPONGBOB PIRATES	WHEEL FAIL BALL CHECK PCB RECEIVING ASPP0PCB004	Part picture
53	MOTOR KGE-0116-ND3657 U1	MOTOR MZZZ0MOT155	Part picture
1.53.2	[MOTOR] SERIAL HUB PCB 20180911	[MOTOR] SERIAL HUB PCB PPCB0DOU575	Part picture
2.53.2	[MOTOR] MOTOR DRIVER IO 190625	[MOTOR] MOTOR DRIVER IO PPCB0DOU576	Part picture
3.53.2	[MOTOR] WHEEL FAIL BALL CHECK PCB TRANSMITTING 190308	[MOTOR] WHEEL FAIL BALL CHECK PCB TRANSMITTING PPCB0DOU577	Part picture
54	BCE CONVEYOR BELT URETHANE 1.4T_GREEN(87*636)	BCE CONVEYOR BELT MSPP0BEL001	Part picture
55	MAIN IO PCB ASS'Y W MOMORY SPONGEBOB PIRATES	MAIN IO PCB ASS'Y W MOMORY ASPP0PCB005	Part picture
3.55.1	[MAIN IO PCB ASS'Y W MOMORY] MAIN IO PCB 20250217	[MAIN IO PCB ASS'Y W MOMORY] MAIN IO PCB PPCB0MUL055	Part picture
56	COUPLING CR050 ASS'Y 8*8_M5_TAB120_M3_18MM	COUPLING CR050 ASS'Y AZZZ0COP001	Part picture
1.56.1	[COUPLING CR050 ASS'Y] COUPLING CR050 8*8_M5_M3_TAB120_18MM	[COUPLING CR050 ASS'Y] COUPLING CR050 MZZZ0COP009	Part picture
57	CHIP HOPPER BASE FRAME ASS'Y .	CHIP HOPPER BASE FRAME ASS'Y ASPP0ASS009	Part picture
1.57.1	[CHIP HOPPER BASE FRAME ASS'Y] WHEEL FAIL BALL CHECK PCB RECEIVING 20191204_EMI	[CHIP HOPPER BASE FRAME ASS'Y] WHEEL FAIL BALL CHECK PCB RECEIVING PPCB0DOU586	Part picture
2.57.1	[CHIP HOPPER BASE FRAME ASS'Y] BSE CHUTE SIDE ACRYL-L ACRYL-4.7T_CLEAR	[CHIP HOPPER BASE FRAME ASS'Y] BSE CHUTE SIDE ACRYL-L MSPG0ACR001	Part picture
3.57.1	[CHIP HOPPER BASE FRAME ASS'Y] BSE CHUTE SIDE ACRYL-R ACRYL-4.7T_CLEAR	[CHIP HOPPER BASE FRAME ASS'Y] BSE CHUTE SIDE ACRYL-R MSPG0ACR002	Part picture
4.57.1	[CHIP HOPPER BASE FRAME ASS'Y] BSE HOUSING COVER ACRYL PC-3.0T_CLEAR	[CHIP HOPPER BASE FRAME ASS'Y] BSE HOUSING COVER ACRYL MSPG0ACR003	Part picture
5.57.1	[CHIP HOPPER BASE FRAME ASS'Y] BSE MOVEMENT SPACER ACRYL ACRYL-8.0T_CLEAR	[CHIP HOPPER BASE FRAME ASS'Y] BSE MOVEMENT SPACER ACRYL MSPG0ACR005	Part picture
6.57.1	[CHIP HOPPER BASE FRAME ASS'Y] BBE CHUTE SIDE ACRYL-L ACRYL-4.7T_CLEAR	[CHIP HOPPER BASE FRAME ASS'Y] BBE CHUTE SIDE ACRYL-L MSPG0ACR006	Part picture
7.57.1	[CHIP HOPPER BASE FRAME ASS'Y] BBE CHUTE SIDE ACRYL-R ACRYL-4.7T_CLEAR	[CHIP HOPPER BASE FRAME ASS'Y] BBE CHUTE SIDE ACRYL-R MSPG0ACR007	Part picture
8.57.1	[CHIP HOPPER BASE FRAME ASS'Y] BBE HOUSING COVER ACRYL ACRYL-4.7T_CLEAR	[CHIP HOPPER BASE FRAME ASS'Y] BBE HOUSING COVER ACRYL MSPG0ACR008	Part picture
9.57.1	[CHIP HOPPER BASE FRAME ASS'Y] BALL FENCE ACRYL-L PET-2.0T_CLEAR	[CHIP HOPPER BASE FRAME ASS'Y] BALL FENCE ACRYL-L MSPG0ACR010	Part picture
10.57.1	[CHIP HOPPER BASE FRAME ASS'Y] BALL FENCE ACRYL-R PET-2.0T_CLEAR	[CHIP HOPPER BASE FRAME ASS'Y] BALL FENCE ACRYL-R MSPG0ACR011	Part picture
11.57.1	[CHIP HOPPER BASE FRAME ASS'Y] CABINET BOTTOM LED FIX ACRYL PET-1.0T_CLEAR	[CHIP HOPPER BASE FRAME ASS'Y] CABINET BOTTOM LED FIX ACRYL MSPG0ACR012	Part picture
12.57.1	[CHIP HOPPER BASE FRAME ASS'Y] CARD OUT LED PCB COVER ACRYL PET-1.0T_CLEAR	[CHIP HOPPER BASE FRAME ASS'Y] CARD OUT LED PCB COVER ACRYL MSPG0ACR014	Part picture
13.57.1	[CHIP HOPPER BASE FRAME ASS'Y] MONITOR SIDE COVER ACRYL ACRYL-4.7T_POINT CLEAR	[CHIP HOPPER BASE FRAME ASS'Y] MONITOR SIDE COVER ACRYL MSPG0ACR017	Part picture
14.57.1	[CHIP HOPPER BASE FRAME ASS'Y] PUSHER SIDE LED PCB COVER ACRYL ACRYL-2.7T_POINT CLEAR	[CHIP HOPPER BASE FRAME ASS'Y] PUSHER SIDE LED PCB COVER ACRYL MSPG0ACR019	Part picture
15.57.1	[CHIP HOPPER BASE FRAME ASS'Y] UPPER PUSHER PLATE FRONT COVER ACRYL ACRYL-4.7T_CLEAR	[CHIP HOPPER BASE FRAME ASS'Y] UPPER PUSHER PLATE FRONT COVER ACRYL MSPG0ACR020	Part picture
16.57.1	[CHIP HOPPER BASE FRAME ASS'Y] UPPER PUSHER PLATE TOP COVER ACRYL ACRYL-4.7T_POINT CLEAR	[CHIP HOPPER BASE FRAME ASS'Y] UPPER PUSHER PLATE TOP COVER ACRYL MSPG0ACR021	Part picture
17.57.1	[CHIP HOPPER BASE FRAME ASS'Y] CARD DISPENSER FRONT MASK ACRYL ACRYL-10T_백색스리	[CHIP HOPPER BASE FRAME ASS'Y] CARD DISPENSER FRONT MASK ACRYL MSPG0ACR044	Part picture
58	BCE BRIDGE SUPPORT SHAFT	BCE BRIDGE SUPPORT SHAFT MSPG0PRO004	Part picture
59	BCE CONVEYOR SUPPORT SHAFT	BCE CONVEYOR SUPPORT SHAFT MSPG0PRO008	Part picture
60	BSE BRAKE REAR SHAFT	BSE BRAKE REAR SHAFT MSPG0PRO009	Part picture
61	BSE BRAKE SHAFT	BSE BRAKE SHAFT MSPG0PRO010	Part picture
62	BSE CENTER BUSHING	BSE CENTER BUSHING MSPG0PRO011	Part picture
63	BSE CHUTE SPACER SHAFT	BSE CHUTE SPACER SHAFT MSPG0PRO012	Part picture
64	BSE SPACE BUSHING	BSE SPACE BUSHING MSPG0PRO014	Part picture
65	BILLBOARD LEFT ACRYL FIX SHAFT	BILLBOARD LEFT ACRYL FIX SHAFT MSPG0PRO015	Part picture
66	BILLBOARD RIGHT ACRYL FIX SHAFT	BILLBOARD RIGHT ACRYL FIX SHAFT MSPG0PRO016	Part picture
67	CABINET MONITOR SIDE ACRYL FIX SHAFT	CABINET MONITOR SIDE ACRYL FIX SHAFT MSPG0PRO019	Part picture
68	BSE BRAKE BUSHING	BSE BRAKE BUSHING MSPG0PRO024	Part picture
69	MOTOR HM37-1232A-M005 (12V, 32RPM)	MOTOR MZZZ0MOT164	Part picture
70	SPRING HINGE HSS-1.2TX30X25(하)_B143	SPRING HINGE MZZZ0HIN009	Part picture
71	BALL STIR AIR HOSE Ø4X70MM_COATING WIRE	BALL STIR AIR HOSE MSPG0ZZZ001	Part picture
72	FLEX_5050_BLUE_1200_NWP_L_72 T5050 TOP 300구 72알	FLEX_5050_BLUE_1200_NWP_L_72 MELE0LED080	Part picture
73	RFID CHIP READER TW-968	RFID CHIP READER MSPG0PAR001	Part picture
74	CARD ASS'Y_SPG 1BOX 150EA	CARD ASS'Y_SPG ASPG0PAR001	Part picture
75	RFID CHIP ASS'Y CODE CHANGE ASPG0PAT017	RFID CHIP ASS'Y ASPG0PAR002	Part picture
76	MONITOR SIDE LED PCB ASS'Y .	MONITOR SIDE LED PCB ASS'Y ASPP0PCB007	Part picture
77	CHIP HOPPER COMMON .	CHIP HOPPER COMMON ASPG0PAR014	Part picture
1.77.1	[CHIP HOPPER COMMON] MEMORY PCB ASS'Y SPG	[CHIP HOPPER COMMON] MEMORY PCB ASS'Y ASPP0PCB008	Part picture
2.77.1	[CHIP HOPPER COMMON] BBE CHUTE FRONT COVER ACRYL .	[CHIP HOPPER COMMON] BBE CHUTE FRONT COVER ACRYL MSPG0ACR045	Part picture
78	COLOR BALL ASS'Y_SBPB 1BOX 1300EA	COLOR BALL ASS'Y_SBPB ASPG0PAT001	Part picture
1.78.1	[COLOR BALL ASS'Y_SBPB] PCB SUPPORT M 5MM	[COLOR BALL ASS'Y_SBPB] PCB SUPPORT MZZZ0PLA057	Part picture
2.78.1	[COLOR BALL ASS'Y_SBPB] CARD DISPENSER IO PCB COVER AV2 ACR_PRI	[COLOR BALL ASS'Y_SBPB] CARD DISPENSER IO PCB COVER AAV20ACP041	Part picture
79	BUTTON SWITCH CWB 401-WHITE 100MM LED	BUTTON SWITCH MZZZ0BUT080	Part picture
80	VOLUME PCB ASS'Y 1 VOLUME	VOLUME PCB ASS'Y AHM20PCB016	Part picture
81	PUSHER BALL SPACE BUSHING	PUSHER BALL SPACE BUSHING MSPG0PRO020	Part picture
1.81.1	[PUSHER BALL SPACE BUSHING] BONUS TARGET SENSOR PCB 20180824	[PUSHER BALL SPACE BUSHING] BONUS TARGET SENSOR PCB PPCB0DOU542	Part picture
82	LED PCB ASS'Y MULTI MAGIC 070618	LED PCB ASS'Y AMUM0PCB005	Part picture
83	COUNTER OA127CL W/2P CONNECTOR_20CM WIRE	COUNTER MZZZ0COU002	Part picture
84	PUSHER GUIDE RAIL 200MM_양쪽 인출방식_100323	PUSHER GUIDE RAIL MSBP0ZZZ011	Part picture
1.84.1	[PUSHER GUIDE RAIL] CARD OUT COVER ACRYL ACRYL-4.7T_CLEAR	[PUSHER GUIDE RAIL] CARD OUT COVER ACRYL MSPG0ACR013	Part picture
85	BCE BRIDGE CAM BUSHING	BCE BRIDGE CAM BUSHING MSPG0PRO001	Part picture
1.85.1	[BCE BRIDGE CAM BUSHING] PHOTO INT-1 PCB ASS'Y ANGLE TYPE	[BCE BRIDGE CAM BUSHING] PHOTO INT-1 PCB ASS'Y AZZZ0PCB103	Part picture
86	PHOTO INT-1 PCB ASS'Y ANGLE TYPE	PHOTO INT-1 PCB ASS'Y AZZZ0PCB103	Part picture
87	CARD ASS'Y_RFID_SPG .	CARD ASS'Y_RFID_SPG ASPG0RFC001	Part picture
1.87.1	[CARD ASS'Y_RFID_SPG] SERIAL 1PORT .	[CARD ASS'Y_RFID_SPG] SERIAL 1PORT MZZZ0000786	Part picture
2.87	[CARD ASS'Y_RFID_SPG] SWIPES_CHTP VALUE SHEET .	[CARD ASS'Y_RFID_SPG] SWIPES_CHTP VALUE SHEET MSPG0SHE038	Part picture
3.87	[CARD ASS'Y_RFID_SPG] SWIPES CHIP NUMBERS SHEET .	[CARD ASS'Y_RFID_SPG] SWIPES CHIP NUMBERS SHEET MSPG0SHE039	Part picture
4.87	[CARD ASS'Y_RFID_SPG] LED PCB COVER .	[CARD ASS'Y_RFID_SPG] LED PCB COVER MAV20ACR070	Part picture
5.87	[CARD ASS'Y_RFID_SPG] BSE HOUSING UPPER COVER ACRYL PET-2.0T_CLEAR	[CARD ASS'Y_RFID_SPG] BSE HOUSING UPPER COVER ACRYL MSPG0ACR051	Part picture
6.87	[CARD ASS'Y_RFID_SPG] SIDE SHEET L_01	[CARD ASS'Y_RFID_SPG] SIDE SHEET L_01 MSPG0SHE015	Part picture
7.87	[CARD ASS'Y_RFID_SPG] SIDE SHEET R_01 .	[CARD ASS'Y_RFID_SPG] SIDE SHEET R_01 MSPG0SHE018	Part picture
8.87	[CARD ASS'Y_RFID_SPG] FRONT BODY DOOR SHE_03 .	[CARD ASS'Y_RFID_SPG] FRONT BODY DOOR SHE_03 MSPG0SHE023	Part picture
9.87	[CARD ASS'Y_RFID_SPG] FRONT DOOR SHE L_04 .	[CARD ASS'Y_RFID_SPG] FRONT DOOR SHE L_04 MSPG0SHE029	Part picture
10.87	[CARD ASS'Y_RFID_SPG] FRONT DOOR SHE R_05 .	[CARD ASS'Y_RFID_SPG] FRONT DOOR SHE R_05 MSPG0SHE030	Part picture
11.87	[CARD ASS'Y_RFID_SPG] BUTTON SHEET .	[CARD ASS'Y_RFID_SPG] BUTTON SHEET MSPG0SHE031	Part picture
12.87	[CARD ASS'Y_RFID_SPG] TARGET SIDE SHEET L .	[CARD ASS'Y_RFID_SPG] TARGET SIDE SHEET L MSPG0SHE032	Part picture
13.87	[CARD ASS'Y_RFID_SPG] TARGET SIDE SHEET R .	[CARD ASS'Y_RFID_SPG] TARGET SIDE SHEET R MSPG0SHE033	Part picture
14.87	[CARD ASS'Y_RFID_SPG] BBE CHUTE SIDE DECO ACRYL-L SPG1	[CARD ASS'Y_RFID_SPG] BBE CHUTE SIDE DECO ACRYL-L ASPG0ACP101	Part picture
15.87	[CARD ASS'Y_RFID_SPG] BBE CHUTE SIDE DECO ACRYL-R SPG1	[CARD ASS'Y_RFID_SPG] BBE CHUTE SIDE DECO ACRYL-R ASPG0ACP102	Part picture
16.87	[CARD ASS'Y_RFID_SPG] BSE TOP SIDE ACRYL-L SPG1	[CARD ASS'Y_RFID_SPG] BSE TOP SIDE ACRYL-L ASPG0ACP103	Part picture
17.87	[CARD ASS'Y_RFID_SPG] BSE TOP SIDE ACRYL-R SPG1	[CARD ASS'Y_RFID_SPG] BSE TOP SIDE ACRYL-R ASPG0ACP104	Part picture
18.87	[CARD ASS'Y_RFID_SPG] BILLBOARD FND COVER ACRYL SPG1	[CARD ASS'Y_RFID_SPG] BILLBOARD FND COVER ACRYL ASPG0ACP105	Part picture
19.87	[CARD ASS'Y_RFID_SPG] BILLBOARD LEFT SIDE ACRYL SPG1	[CARD ASS'Y_RFID_SPG] BILLBOARD LEFT SIDE ACRYL ASPG0ACP106	Part picture
20.87	[CARD ASS'Y_RFID_SPG] BILLBOARD RIGHT SIDE ACRYL SPG1	[CARD ASS'Y_RFID_SPG] BILLBOARD RIGHT SIDE ACRYL ASPG0ACP107	Part picture
21.87	[CARD ASS'Y_RFID_SPG] BUTTON PLATE COVER ACRYL-L SPG1	[CARD ASS'Y_RFID_SPG] BUTTON PLATE COVER ACRYL-L ASPG0ACP108	Part picture
22.87	[CARD ASS'Y_RFID_SPG] CABINET MONITOR SIDE ACRYL-L SPG1	[CARD ASS'Y_RFID_SPG] CABINET MONITOR SIDE ACRYL-L ASPG0ACP110	Part picture
23.87	[CARD ASS'Y_RFID_SPG] CABINET MONITOR SIDE ACRYL-R SPG1	[CARD ASS'Y_RFID_SPG] CABINET MONITOR SIDE ACRYL-R ASPG0ACP111	Part picture
24.87	[CARD ASS'Y_RFID_SPG] CARD DISPENSER SIDE COVER ACRYL-R SPG1	[CARD ASS'Y_RFID_SPG] CARD DISPENSER SIDE COVER ACRYL-R ASPG0ACP113	Part picture
25.87	[CARD ASS'Y_RFID_SPG] CARD DISPLAY COVER ACRYL_50 SPG1	[CARD ASS'Y_RFID_SPG] CARD DISPLAY COVER ACRYL_50 ASPG0ACP114	Part picture
26.87	[CARD ASS'Y_RFID_SPG] MIDDLE DISPLAY COVER ACRYL SPG1	[CARD ASS'Y_RFID_SPG] MIDDLE DISPLAY COVER ACRYL ASPG0ACP115	Part picture
27.87	[CARD ASS'Y_RFID_SPG] MONITOR BEZEL ACRYL SPG1	[CARD ASS'Y_RFID_SPG] MONITOR BEZEL ACRYL ASPG0ACP116	Part picture
28.87	[CARD ASS'Y_RFID_SPG] SPEAKER COVER ACRYL SPG1	[CARD ASS'Y_RFID_SPG] SPEAKER COVER ACRYL ASPG0ACP117	Part picture
29.87	[CARD ASS'Y_RFID_SPG] BONUS TARGET CHECKER COVER ACRYL SPG1	[CARD ASS'Y_RFID_SPG] BONUS TARGET CHECKER COVER ACRYL ASPG0ACP118	Part picture
30.87	[CARD ASS'Y_RFID_SPG] BONUS TARGET FRONT ACRYL SPG1	[CARD ASS'Y_RFID_SPG] BONUS TARGET FRONT ACRYL ASPG0ACP119	Part picture
31.87	[CARD ASS'Y_RFID_SPG] BSE CHUTE SIDE DECO ACRYL-L SPG1	[CARD ASS'Y_RFID_SPG] BSE CHUTE SIDE DECO ACRYL-L ASPG0ACP120	Part picture
32.87	[CARD ASS'Y_RFID_SPG] BSE CHUTE SIDE DECO ACRYL-R SPG1	[CARD ASS'Y_RFID_SPG] BSE CHUTE SIDE DECO ACRYL-R ASPG0ACP121	Part picture
33.87	[CARD ASS'Y_RFID_SPG] CONTROL PANEL COVER ACRYL SPG1	[CARD ASS'Y_RFID_SPG] CONTROL PANEL COVER ACRYL ASPG0ACP122	Part picture
34.87	[CARD ASS'Y_RFID_SPG] MONITOR BEZEL FRONT LOWER COVER ACRYL SPG1	[CARD ASS'Y_RFID_SPG] MONITOR BEZEL FRONT LOWER COVER ACRYL ASPG0ACP123	Part picture
35.87	[CARD ASS'Y_RFID_SPG] MONITOR BEZEL FRONT UPPER COVER ACRYL SPG1	[CARD ASS'Y_RFID_SPG] MONITOR BEZEL FRONT UPPER COVER ACRYL ASPG0ACP124	Part picture
36.87	[CARD ASS'Y_RFID_SPG] BSE RAIL SIDE DECO ACRYL-L SPG1	[CARD ASS'Y_RFID_SPG] BSE RAIL SIDE DECO ACRYL-L ASPG0ACP125	Part picture
37.87	[CARD ASS'Y_RFID_SPG] BSE RAIL SIDE DECO ACRYL-R SPG1	[CARD ASS'Y_RFID_SPG] BSE RAIL SIDE DECO ACRYL-R ASPG0ACP126	Part picture
38.87	[CARD ASS'Y_RFID_SPG] BBE RAIL SIDE DECO ACRYL-L SPG1	[CARD ASS'Y_RFID_SPG] BBE RAIL SIDE DECO ACRYL-L ASPG0ACP127	Part picture
39.87	[CARD ASS'Y_RFID_SPG] BBE RAIL SIDE DECO ACRYL-R SPG1	[CARD ASS'Y_RFID_SPG] BBE RAIL SIDE DECO ACRYL-R ASPG0ACP128	Part picture
40.87	[CARD ASS'Y_RFID_SPG] HTP CENTER ACRYL SPG1	[CARD ASS'Y_RFID_SPG] HTP CENTER ACRYL ASPG0ACP129	Part picture
41.87	[CARD ASS'Y_RFID_SPG] CONTROL PANEL FRONT BKT PRINT SPG1	[CARD ASS'Y_RFID_SPG] CONTROL PANEL FRONT BKT PRINT ASPG0ACP130	Part picture
42.87	[CARD ASS'Y_RFID_SPG] ATX POWER SUPPLY FSP350-50TAC	[CARD ASS'Y_RFID_SPG] ATX POWER SUPPLY MELE0SMP149	Part picture
42.87.1	[CARD ASS'Y_RFID_SPG] MAIN BOARD GIGA-H510M H	[CARD ASS'Y_RFID_SPG] MAIN BOARD MZZZ0PCB096	Part picture
43.87	[CARD ASS'Y_RFID_SPG] MAIN BOARD GIGA-H510M H	[CARD ASS'Y_RFID_SPG] MAIN BOARD MZZZ0PCB096	Part picture
43.87.1	[CARD ASS'Y_RFID_SPG] VGA CARD GV-N 1030D5-2GL	[CARD ASS'Y_RFID_SPG] VGA CARD MZZZ0PCB097	Part picture
44.87	[CARD ASS'Y_RFID_SPG] VGA CARD GV-N 1030D5-2GL	[CARD ASS'Y_RFID_SPG] VGA CARD MZZZ0PCB097	Part picture
88	RFID CHIP ASS'Y V2 3COLOR R_60 B_120 G_120	RFID CHIP ASS'Y V2 ASPG0PAT017	Part picture
1.88	[RFID CHIP ASS'Y V2] VALUE BLANK SHEET 영국향	[RFID CHIP ASS'Y V2] VALUE BLANK SHEET MSPG0SHE046	Part picture
89	A_CARD DISPENSOR_COMMON A CODE CHANGE AZZZ0ASS115	A_CARD DISPENSOR_COMMON A AZZZ0ASS079	Part picture
90	A_CARD DISPENSER_COMMON L CODE CHANGE AZZZ0ASS115	A_CARD DISPENSER_COMMON L AZZZ0ASS081	Part picture
1.90	[A_CARD DISPENSER_COMMON L] CHIP COVER BKT SHE_L 남코	[A_CARD DISPENSER_COMMON L] CHIP COVER BKT SHE_L MSPG0SHE044	Part picture
2.90	[A_CARD DISPENSER_COMMON L] CHIP COVER BKT SHE_R 남코	[A_CARD DISPENSER_COMMON L] CHIP COVER BKT SHE_R MSPG0SHE045	Part picture
3.90	[A_CARD DISPENSER_COMMON L] VALUE BLANK SHEET .	[A_CARD DISPENSER_COMMON L] VALUE BLANK SHEET MSPG0SHE047	Part picture
91	MAIN BOX ASS'Y SPG_MK7	MAIN BOX ASS'Y ASPG0SYS001	Part picture
1.91	[MAIN BOX ASS'Y] CARD DISPENSER SIDE COVER ACRYL-L SPG1	[MAIN BOX ASS'Y] CARD DISPENSER SIDE COVER ACRYL-L ASPG0ACP112	Part picture
2.91	[MAIN BOX ASS'Y] HTP CENTER ACRYL SHEET+ACRYL SPG	[MAIN BOX ASS'Y] HTP CENTER ACRYL ASPG0ACP132	Part picture
3.91	[MAIN BOX ASS'Y] SIDE SHEET L_02~03 SHE016~017	[MAIN BOX ASS'Y] SIDE SHEET L_02~03 ASPG0SHE001	Part picture
4.91	[MAIN BOX ASS'Y] SIDE SHEET R_02~03 SHE019~020	[MAIN BOX ASS'Y] SIDE SHEET R_02~03 ASPG0SHE002	Part picture
5.91	[MAIN BOX ASS'Y] FRONT DOOR SHE L_01~02 03 SHE026~028	[MAIN BOX ASS'Y] FRONT DOOR SHE L_01~02 03 ASPG0SHE003	Part picture
6.91	[MAIN BOX ASS'Y] FRONT BODY DOOR SHE_01~02 SHE021~022	[MAIN BOX ASS'Y] FRONT BODY DOOR SHE_01~02 ASPG0SHE004	Part picture
7.91	[MAIN BOX ASS'Y] FRONT BODY DOOR SHE_04~05 SHE024~025	[MAIN BOX ASS'Y] FRONT BODY DOOR SHE_04~05 ASPG0SHE005	Part picture
8.91	[MAIN BOX ASS'Y] FRONT BODY SHEET_01~02 SHE040~041	[MAIN BOX ASS'Y] FRONT BODY SHEET_01~02 ASPG0SHE006	Part picture
9.91	[MAIN BOX ASS'Y] FRONT BODY SHEET_04~05 SHE042~043	[MAIN BOX ASS'Y] FRONT BODY SHEET_04~05 ASPG0SHE007	Part picture
92	WEB ACRYL PART WEB SPG	WEB ACRYL PART ASPG0PAT033	Part picture
93	WEB SHEET PART WEB SPG	WEB SHEET PART ASPG0PAT034	Part picture
